Total capacity: 0.6 L (air and liquid)
Pre-pressurization: 1.4 BAR - 20 PSI
Maximum pressure: 8.6 BAR - 125 PSI
Connection: 1/2" male
Do not exceed 40 PSI for long-term storage or when not in use.
Pre-charge is recommended to be checked once every season.
A standard tire pressure gauge may be used to check the pressure.
This unit may be installed anywhere in the pressurized side of your plumbing.
Mountable in any position.
For winterizing or sanitizing, it is recommended to mount with the pre-charge valve stem facing up.
Do not allow to freeze or mount near a high heat source.
